TFI 106MY CNC Turning and Milling Lathe: Precision and Power for Industrial Production

Overview of TFI 106MY CNC Lathe

The TFI 106MY CNC Turning and Milling Lathe is a full-function, high-speed, and high-precision CNC machine designed for modern industrial production lines. Tailored for manufacturers in Belarus (Minsk) and Russia (Moscow), this model ensures exceptional stability, rigidity, and long-term operational reliability, making it ideal for producing small and medium-sized precision components.

Applications Across Industries

According to the official technical catalog, the TFI 106MY is widely utilized in various industries, including automotive manufacturing, electronics, home appliances, aerospace, mold production, medical equipment, and precision instruments.

Key Features and Technology

The machine is equipped with a high-power, high-torque spindle featuring Japan NSK P4-level high-precision bearings, ensuring superior machining accuracy and efficiency. It includes a 12-position BMT55 servo power turret with a coolant-through system, utilizing servo motor indexing, tooth coupling positioning, and hydraulic locking for rapid tool changes, enhanced rigidity, and precise positioning.

The X and Z axes are powered by C3-level Japan THK precision ball screws paired with THK P-level linear roller guide rails, delivering smooth motion and excellent dynamic performance. Additionally, the integrated 30-degree slant bed casting structure improves bending resistance and torsional rigidity, guaranteeing overall machine stability during heavy-duty operations.

Technical Specifications

• Maximum swing over bed: 500 mm
• Maximum machining diameter: 400 mm
• Maximum machining length: 500 mm
• Spindle speed: Up to 5000 rpm
• Spindle motor power: 11 kW
• X-axis and Z-axis servo motor power: 2.4 kW each
• Milling motor power: 3.1 kW
• Machine dimensions: 2620 × 1700 × 1920 mm
• Total weight: 4200 kg

Advanced Control and Eco-Friendly Design

The TFI 106MY is equipped with a Taiwan SYNTEC 22TA CNC control system, offering advanced and stable industrial operation. Its eco-friendly design features centralized lubrication, reduced oil consumption, an enclosed protection structure, and an energy-saving standby mode.

Optional Accessories for Customization

To meet specific factory production requirements, optional accessories are available, including automatic bar feeders, chip removal systems, hydraulic chucks, tool setters, live tool holders, and other configurable solutions.

Ideal for Industrial Workshops in Minsk and Moscow

The TFI 106MY CNC Turning and Milling Lathe is a perfect solution for industrial workshops and manufacturing facilities in Minsk and Moscow looking for reliable, high-precision CNC machining equipment.
