86° Straight Punch Silver Class H100 B26 EU3214
Straight Punch Silver Class 86° — “H100mm B26mm” – EU3214
REFERENCE:
BPS_100_26_86
CONDITION:
New product
EU3214 SASH punch — 100mm working height, 26mm body, 86°. Inward-angled tip provides access to both sides of a bend in a single stroke. Silver Class. For window frames, door jambs, and architectural profiles across the UAE and GCC.
DATA SHEET
- Length 3200 mm
- Width 100 mm
- Thickness 26 mm
MORE INFO
Technical Specifications
- Punch Height (H) 100.00 mm
- Body Thickness (B) 26.00 mm
- Bending Angle 86.00°
- Material Grade 42CrMo4
- Tolerance Class DIN 7168 Fine
- Standard Set Length 835 mm
- Segment Composition 5×150mm + 2×42.5mm
- Product Grade Silver Class
- EU Drawing Reference EU3214
Clamp System Compatibility
- AFH / Euro Style — AMADA™, Bystronic™, Durma™, Ermaksan™, and most Euro-clamp CNC press brakes
- AMADA™ Direct-Mount — AMADA™ native clamp systems
Parameters Confirmed Upon Order
The following parameters are customer-defined. TFI Co. will confirm these via email upon receipt of order:
- Tip Radius (R): Standard options: 0.6 mm / 0.8 mm / 1 mm. Custom radius available on request.
- Segment Composition: Standard configuration: 5×150mm + 2×42.5mm. Custom segment arrangement available at no extra cost.
A compact SASH punch with a 100 mm working height and narrow 26 mm body, shaped with the characteristic inward-angled tip that gives operators access to both sides of a bend. Designed for window frame profiles, door jambs, and architectural sashes where a standard straight punch would obstruct the workpiece. The 86° bending angle produces a crisp, sharp profile on both faces of the formed part — ideal for framing components and structural sections that demand angles on both sides of the bend in a single stroke.
TFI Co. provides precision press brake tooling for the metalworking industry, manufactured from 42CrMo (Chromium-Molybdenum Steel) — hard, precision-ground, and well-tested for multi-stage bending and box-forming applications. Precision-hardened to 52 HRC, all body thickness dimensions conform to DIN 7168 tolerance standards.
Available for immediate delivery across the UAE (Abu Dhabi, Dubai, Sharjah, Ajman, Ras Al Khaimah), the Kingdom of Saudi Arabia, Oman, and Qatar from TFI Co. logistics centres. All punch segment sets include one left ear and one right ear piece.
All tools come with a maximum tonnage capacity. TFI Co. strongly advises all customers to stay within the rated capacity for staff safety, and to only apply the stated maximum force — not more.
Technical Disclaimer & Pricing Notice
TFI Co. provides these technical specifications as a reference only. TFI Co. provides these technical specifications as a reference only. TFI Co. accepts no liability if a third-party manufacturer applies these specifications and is unable to achieve equivalent product quality. The manufacturing outcomes of any external production facility are entirely beyond TFI Co.’s control and responsibility.
All prices shown on this page are indicative estimates only and are subject to market fluctuation. For precise and up-to-date pricing, please contact us directly — scan the QR code printed on the product images, use the live chat button on this page, or find the contact number for your region at the bottom of this page.
TFI Co., manufacturer of steel blades and machine knives since 1965, offers the EU3214 86° Straight Punch Silver Class with 100 mm working height and 26 mm body thickness as part of its precision press brake tooling range supplied to metal fabricators and production managers across the UAE and GCC. This inward-angled SASH punch solves the common restriction of accessing both sides of a bend in a single stroke on window frames, door jambs, and architectural profiles, delivering the exact BPS_100_26_86 geometry and 3200 mm length specifications needed for efficient metalworking setups. Readers can review the full technical data on this page to evaluate suitability, compare against existing inventory, and confidently procure the correct tool for their bending operations.
Fast Facts
- Punches equipped with inward-angled tips provide access to both sides of bends in single strokes.
- Long-established manufacturers supply industrial steel blades and press brake tools since 1965 to GCC markets.
- Metal fabricators employ 86-degree straight punches for precise architectural metal bending applications.
- Factory buyers purchase silver class punches for window frame and door jamb production.
- Maintenance teams install new punches with 100 millimeter height for sustained production efficiency.
Certifications
Confirmation of certifications, standards, and accreditations is available on request.
Used by metal fabricators, factory buyers, maintenance teams, production managers, and industrial procurement teams. Trusted across industrial metalworking applications with our shear blades, circular saw blades, bandsaw blades, slitter knives, rebar cutting blades, and press brake tools. Manufacturer of Steel Blades Since 1965.
Warranty: The site offers customised confirmation on request for warranty, replacement, and support.
Technical Parameters
| Product Type | 86° Straight Punch |
|---|---|
| Class | Silver Class |
| Reference | BPS_100_26_86 |
| Model | EU3214 |
| Condition | New product |
| Punch Height | 100.00 mm |
| Body Thickness | 26.00 mm |
| Length | 3200 mm |
| Bend Angle | 86° |
| Design Feature | Inward-angled tip for access to both sides of a bend in a single stroke |
| Application | Window frames, door jambs, and architectural profiles |
| Compatibility | Press brake tools for metalworking in UAE and GCC |
| Manufacturer | TFI Co. since 1965 |
Where It Works
- Press Brake Use Case: Forming precise bends on window frames with the 86° inward-angled tip allowing single-stroke access to both sides of the bend.
- Metal Fabricators: Enables metal fabricators to produce door jambs using the H100 B26 EU3214 straight punch in high-accuracy press brake setups.
- Architectural Profile Production: Supports single-operation bending of architectural profiles with the Silver Class 86° punch in dedicated metalworking workflows.
- UAE Maintenance Teams: Used by maintenance teams in UAE facilities for rapid replacement and calibration of press brake punches matching BPS_100_26_86 specifications.
- GCC Production Managers: Assists production managers across GCC plants in optimizing press brake sequences for window frames and door jambs.
- Industrial Procurement: Sourced by industrial procurement teams for durable Silver Class tooling compatible with existing press brake machines in metal fabrication.
- High-Volume Bending Operations: Applied in continuous production lines where the 100 mm punch height and 26 mm body enable efficient architectural metal profile forming.
Expert Answers
What is the 86° Straight Punch Silver Class H100 B26 EU3214?
The 86° Straight Punch Silver Class H100 B26 EU3214 is a new SASH punch offering 100mm working height, 26mm body and 86° inward-angled tip. The design provides access to both sides of a bend in a single stroke. It is intended for window frames, door jambs and architectural profiles across the UAE and GCC. TFI Co. is a manufacturer of steel blades since 1965 providing these industrial tools.
How does the inward-angled tip on the 86° Straight Punch function?
The inward-angled tip on the 86° Straight Punch Silver Class enables access to both sides of a bend in a single stroke. This improves efficiency for metal fabricators and production managers using the H100 B26 EU3214 model. The design reduces the need for multiple setups when working on complex architectural profiles and door jambs in GCC press brake operations.
Can the Silver Class H100 B26 punch be used for architectural profiles in the GCC?
Yes, the EU3214 SASH punch is designed for window frames, door jambs, and architectural profiles across the UAE and GCC. With its 86° angle and inward-angled tip, the Silver Class H100 B26 tool delivers precise results. It allows access to both sides of a bend in one stroke, making it valuable for expert industrial teams.
Does the EU3214 punch have a length of 3200 mm?
Yes, according to the data sheet the 86° Straight Punch Silver Class H100 B26 EU3214 has a length of 3200 mm along with 100 mm width and 26 mm thickness. Technical specifications list the punch height at 100.00 mm and body thickness at 26.00 mm. These dimensions support its application in heavy-duty bending for the regional market.
Which reference number corresponds to the 86° Straight Punch Silver Class H100 B26?
The reference BPS_100_26_86 corresponds to the 86° Straight Punch Silver Class H100 B26 also known as EU3214. This new product includes an inward-angled tip for single stroke access to both bend sides. It is manufactured for use in window frames, door jambs and architectural profiles in the UAE and GCC by TFI Co. since 1965.
How can I purchase the 86° Straight Punch Silver Class H100 B26 EU3214?
To obtin this specific 86° Straight Punch Silver Class with 100mm working height for your window frames and architectural profiles in the UAE and GCC, use Chat for the fastest response. You may also submit the online form or call. TFI Co., manufacturer of steel blades and machine knives since 1965, supplies these precision items to industrial buyers.
