86° Straight Punch Silver Class H130 B26 EU3111
Straight Punch Silver Class 86° — “H130mm B26mm” – “EU3111”
REFERENCE: BPS_130_26_86_111
CONDITION: New product
EU3111 — 130mm working height 3100 series straight punch, 26mm body, 86° angle. Silver Class. Precision sharp-angle bending for brackets, panels, and structural profiles — fully interchangeable within the 3100 series across the UAE and GCC.
MORE INFO
Technical Specifications
- Punch Height (H): 130.00 mm
- Body Thickness (B): 26.00 mm
- Bending Angle: 86.00°
- Material Grade: 42CrMo4
- Tolerance Class: DIN 7168 Fine
- Standard Set Length: 835 mm
- Segment Composition: 5×150mm + 2×42.5mm
- Product Grade: Silver Class
- EU Drawing Reference: EU3111
Clamp System Compatibility
- AFH / Euro Style — AMADA™, Bystronic™, Durma™, Ermaksan™, and most Euro-clamp CNC press brakes
- AMADA™ Direct-Mount — AMADA™ native clamp systems
Parameters Confirmed Upon Order
The following parameters are customer-defined. TFI Co. will confirm these via email upon receipt of order:
- Tip Radius (R): Standard options: 0.6 mm / 0.8 mm / 1 mm. Custom radius available on request.
- Segment Composition: Standard configuration: 5×150mm + 2×42.5mm. Custom segment arrangement available at no extra cost.
A standard 86° straight punch — 130 mm working height, 26 mm body — from the 3100 series family. Precision-machined for sharp, consistent bending across brackets, panels, and structural profiles in daily production. The 3100 series profile is specified where straightforward 86° forming at moderate box depth is the requirement, and where tool interchangeability across a mixed 3100 series set is an advantage in flexible manufacturing environments.
TFI Co. provides precision press brake tooling for the metalworking industry, manufactured from 42CrMo (Chromium-Molybdenum Steel) — hard, precision-ground, and well-tested for multi-stage bending and box-forming applications. Precision-hardened to 52 HRC, all body thickness dimensions conform to DIN 7168 tolerance standards.
Available for immediate delivery across the UAE (Abu Dhabi, Dubai, Sharjah, Ajman, Ras Al Khaimah), the Kingdom of Saudi Arabia, Oman, and Qatar from TFI Co. logistics centres. All punch segment sets include one left ear and one right ear piece.
All tools come with a maximum tonnage capacity. TFI Co. strongly advises all customers to stay within the rated capacity for staff safety, and to only apply the stated maximum force — not more.
Technical Reference Disclaimer & Pricing Notice
TFI Co. provides these technical specifications as a reference only. TFI Co. provides these technical specifications as a reference only. TFI Co. accepts no liability if a third-party manufacturer applies these specifications and is unable to achieve equivalent product quality. The manufacturing outcomes of any external production facility are entirely beyond TFI Co.’s control and responsibility.
Pricing & Contact
All prices shown on this page are indicative estimates only and are subject to market fluctuation. For precise and up-to-date pricing, please contact us directly — scan the QR code printed on the product images, use the live chat button on this page, or find the contact number for your region at the bottom of this page.
TFI Co. manufactures and supplies the 86° Straight Punch Silver Class H130 B26 EU3111 reference BPS_130_26_86_111 as part of our established range of press brake tools for metal fabricators and production teams across the UAE, Saudi Arabia, Oman, GCC, and wider Middle East markets. Since 1965 we have delivered precision 42CrMo4 punches with 130 mm working height, 26 mm body thickness, and 86° angle that solve the requirement for accurate sharp-angle bending of brackets, panels, and structural profiles while remaining fully interchangeable within the 3100 series. Readers can evaluate exact tolerances and compatibility details on this page to make informed procurement decisions that maintain output quality and reduce tooling changeover time in industrial metalworking operations.
Essential Points
- Precision straight punches create 86-degree angles in press brake metal bending operations.
- Manufacturers supply durable punches to industrial buyers across UAE and GCC markets since 1965.
- Metal fabricators achieve accurate results using Silver Class punches on structural profiles.
- Production managers select interchangeable tooling to reduce maintenance time in factories.
- Fabrication teams apply straight punches when forming brackets and panels with precision.
Trust & Credentials
Customised confirmation of standards and qualifications is available on request.
Used by metal fabricators, factory buyers, maintenance teams, production managers, and industrial procurement teams across the UAE, Saudi Arabia, Oman, GCC, and the wider Middle East. Trusted across regional metalworking applications as Manufacturer of Steel Blades Since 1965 for precision shear blades, circular saw blades, bandsaw blades, slitter knives, rebar cutting blades, and press brake tools.
Warranty: The site offers customised confirmation on warranty, replacement, and support terms on request.
Engineering Data
| Product Type | Straight Punch |
|---|---|
| Class | Silver Class |
| Model | EU3111 |
| Reference | BPS_130_26_86_111 |
| Condition | New |
| Punch Height | 130.00 mm |
| Body Thickness | 26.00 mm |
| Bending Angle | 86.00° |
| Material Grade | 42CrMo4 |
| Series | 3100 sries |
| Compatibility | Fully interchangeable within 3100 series press brake tools |
| Application | Precision sharp-angle bending for brackets, panels, and structural profiles in metalworking |
| Regional Use | UAE and GCC |
| Manufacturer | TFI Co. since 1965 |
Sectors We Serve
- Precision Bending Use Case: Precision 86° angle bending of brackets and supports with 130 mm working height straight punches in metal fabrication workflows.
- Panel Fabrication: Sharp-angle forming of panels and enclosures using Silver Class H130 B26 punches interchangeable within the 3100 series.
- Structural Profiles: Bending structural profiles for industrial frames and assemblies on press brakes equipped with EU3111 straight punches.
- UAE Maintenance Teams: Maintenance teams in UAE facilities performing rapid tool changes on 42CrMo4 press brake punches to reduce downtime since 1965.
- GCC Production Managers: Production managers in GCC metalworking plants specifying 86° straight punches for repeatable accuracy on high-volume lines.
- Saudi Procurement Teams: Industrial procurement teams in Saudi Arabia sourcing interchangeable 3100 series punches for long-term press brake tooling requirements.
- Oman Metal Fabricators: Metal fabricators in Oman deploying Silver Class straight punches for brackets, panels, and profiles in structural fabrication.
- Middle East Context: High-precision bending operations across Middle East manufacturing environments using TFI Co. press brake tools since 1965.
What Buyers Ask
What is the 86° Straight Punch Silver Class H130 B26 EU3111?
Manufactured by TFI Co. since 1965, the EU3111 is a new 3100 series straight punch featuring 130mm working height, 26mm body thickness, and an 86° bending angle. Produced in 42CrMo4 material as Silver Class, it enables precision sharp-angle bending for brackets, panels, and structural profiles. The tool is fully interchangeable within the 3100 series across UAE and GCC markets.
How is the H130 B26 EU3111 punch applied in fabrication?
The 86° Straight Punch is applied in press brake operations requiring sharp-angle bends at 86 degrees. Its design supports accurate forming of brackets, panels, and structural profiles with the 130mm height providing necessary clearance and the 26mm body ensuring rigidity during bending cycles. This makes it ideal for production teams in the GCC region seeking reliable performance.
Can the Silver Class EU3111 punch be interchanged with other 3100 series tools?
Yes, the EU3111 86° straight punch is fully interchangeable within the 3100 series. Fabricators in the UAE, Saudi Araba, and across the GCC can directly replace or combine it with compatible 3100 series press brake tooling without adaptation, supporting efficient workflow for precision bending of metal components using its 42CrMo4 construction.
Does the 86° Straight Punch H130 B26 meet requirements for structural profile bending?
Yes, the EU3111 is specifically designed for precision sharp-angle bending of brackets, panels, and structural profiles. With its 86° angle, 130mm working height, and 26mm body in 42CrMo4 grade, this Silver Class tool from TFI Co. since 1965 delivers the accuracy and durability demanded by industrial maintenance and production teams throughout the Middle East.
Which material grade is used for the EU3111 Straight Punch?
The EU3111 86° Straight Punch Silver Class utilizes 42CrMo4 material grade. This high-strength alloy combined with 130mm height, 26mm thickness, and precise 86° angle ensures long-term performance in 3100 series press brake applications for sharp bending tasks. As a new product from TFI Co., manufacturer of steel blades since 1965, it serves regional industrial buyers effectively.
How can I purchase the 86° Straight Punch Silver Class EU3111 for use in the GCC?
To acquire this 130mm H130 B26 86° straight punch in 42CrMo4 for your precision bending applications in the UAE or GCC, reach out via Chat for the fastest response. Alternatively, complete the onlne form or call our team. As manufacturer since 1965, TFI Co. supplies this new interchangeable 3100 series tool directly to industrial buyers in the region.
TFI Co. certifies every blade meets the specifications above — correct hardness, geometry, and material grade, verified under ISO 9001:2015 before shipment. Achieving the stated performance figures also requires correct installation, operation within rated parameters, and scheduled maintenance. Contact our technical team to validate blade selection for your specific application.
TFI Co. commits to manufacturing precision press brake tools for industrial metal fabricators in UAE, GCC and wider regional markets.
- Supplying the 86° Straight Punch Silver Class H130 B26 EU3111 in 42CrMo4 for accurate sharp-angle bending of brackets, panels and structural profiles.
- Delivering 130 mm working height punches fully interchangeable within the 3100 series for pressbrake operations across Saudi Arabia, Oman and GCC buyers.
- Supporting metalworking workflows with tools produced to stated specifications since 1965 while values may vary by context.
