Straight Punch 30° Silver H150mm B26mm EU3212 SMAX
Straight Punch Silver Class 30° — “H150mm B26mm” – “EU3212 SMAX”
Reference:
BPS_150_26_30_S
Condition:
New product
EU3212-S-MAX — 150mm working height S-body joggle punch, 26mm body, 30° angle. Silver Class. Stepped offset flange forming at depth for complex architectural and enclosure assemblies across the UAE and GCC.
Data sheet
- Length: 3200 mm
- Width: 150 mm
- Thickness: 26 mm
More info
Technical Specifications
- Punch Height (H): 150.00 mm
- Body Thickness (B): 26.00 mm
- Bending Angle: 30.00°
- Material Grade: 42CrMo4
- Tolerance Class: DIN 7168 Fine
- Standard Set Length: 835 mm
- Segment Composition: 5×150mm + 2×42.5mm
- Product Grade: Silver Class
- EU Drawing Reference: EU3212
Clamp System Compatibility
- AFH / Euro Style — AMADA™, Bystronic™, Durma™, Ermaksan™, and most Euro-clamp CNC press brakes
- AMADA™ Direct-Mount — AMADA™ native clamp systems
Parameters Confirmed Upon Order
The following parameters are customer-defined. TFI Co. will confirm these via email upon receipt of order:
- Tip Radius (R): Standard options: 0.6 mm / 0.8 mm / 1 mm. Custom radius available on request.
- Segment Composition: Standard configuration: 5×150mm + 2×42.5mm. Custom segment arrangement available at no extra cost.
The tall S-body offset punch at 150 mm working height — for deeper box assemblies with stepped profiles that require the offset Z-bend geometry at greater forming depth. Same acute 30° angle in the S-body that creates the flanged step in one stroke, with the added height providing clearance for workpieces with pre-formed legs or side walls. For complex architectural and enclosure parts where both acute angle and offset geometry are required in a single tool.
TFI Co. provides precision press brake tooling for the metalworking industry, manufactured from 42CrMo (Chromium-Molybdenum Steel) — hard, precision-ground, and well-tested for multi-stage bending and box-forming applications. Precision-hardened to 52 HRC, all body thickness dimensions conform to DIN 7168 tolerance standards.
Available for immediate delivery across the UAE (Abu Dhabi, Dubai, Sharjah, Ajman, Ras Al Khaimah), the Kingdom of Saudi Arabia, Oman, and Qatar from TFI Co. logistics centres. All punch segment sets include one left ear and one right ear piece.
All tools come with a maximum tonnage capacity. TFI Co. strongly advises all customers to stay within the rated capacity for staff safety, and to only apply the stated maximum force — not more.
Technical Specifications & Pricing Disclaimer
TFI Co. provides these technical specifications as a reference only. TFI Co. accepts no liability if a third-party manufacturer applies these specifications and is unable to achieve equivalent product quality. The manufacturing outcomes of any external production facility are entirely beyond TFI Co.’s control and responsibility.
All prices shown on this page are indicative estimates only and are subject to market fluctuation. For precise and up-to-date pricing, please contact us directly — scan the QR code printed on the product images, use the live chat button on this page, or find the contact number for your region at the bottom of this page.
TFI Co. supplies the Straight Punch 30° Silver H150mm B26mm EU3212 SMAX (EU3212-S-MAX, reference BPS_150_26_30_S), a 150 mm working-height S-body joggle punch with 26 mm body and 30° angle, as part of its press brake tooling range manufactured since 1965. This dedicated product page gives metal fabricators, production managers, and procurement teams in the UAE and GCC the exact specifications and application data needed to evaluate and select the tool for stepped offset flange forming in complex architectural and enclosure assemblies. Readers finish with clear, actionable understanding of its dimensions and performance so they can specify the correct industrial knife or press brake tool for reliable metalworking results.
Core Advantages
- Silver class punches feature 150mm height with 26mm thickness at 30-degree angle.
- Manufacturers supply durble press brake tools to industrial buyers in GCC markets since 1965.
- Production managers depend on silver class punches for reliable daily metal fabrication.
- Complex architectural assemblies require straight punches for stepped offset flange forming.
- Metal fabricators procure precision tools to optimize bending operations in enclosure production.
Standards & Compliance
Customised confirmation of certifications, material standards and qualifications is available on request.
Used by metal fabricators, factory buyers, maintenance teams, production managers, and industrial procurement teams across the UAE, Saudi Arabia, Oman, GCC, and wider Middle East for precision press brake tools and industrial cutting applications. Trusted across metalworking and enclosure assembly projects as Manufcturer of Steel Blades Since 1965.
Warranty: Customised confirmation of guarantee, replacement and support options is available on request.
Specification Table
| Product Type | Straight Punch |
|---|---|
| Class | SilverClass |
| Body Style | S-body joggle punch |
| Angle | 30° |
| Punch Height | 150.00 mm |
| Body Width | 26 mm |
| Overall Length | 3200 mm |
| Tool Width | 150 mm |
| Tool Thickness | 26 mm |
| Reference | BPS_150_26_30_S |
| Model | EU3212 SMAX |
| Function | Stepped offset flange forming for complex architectural and enclosure assemblies |
| Compatibility | Press brake tools for metalworking applications in UAE and GCC |
| Manufacturer | TFI Co. Snce 1965 |
| Condition | New product |
Suitable Industries
- Use Case: Stepped offset flange forming at depth using 30° straight punches for complex architectural assemblies.
- Audience: Metal fabricators in the UAE producing custom enclosure panels with EU3212 SMAX press brake tools.
- Context: High-precision joggle bending workflows in GCC sheet metal fabrication facilities.
- Use Case: Creating 30° angled offsets in aluminum and steel enclosures for infrastructure projects across the Middle East.
- Audience: Production managers in Saudi Arabian plants maintaining consistent press brake tooling performance.
- Context: Press brake setups in Omani manufacturing environments requiring H150mm B26mm silver class punches.
- Use Case: Offset flange operations at specified depth in architectural metalworking using SMAX series straight punches.
- Audience: Industrial procurement teams sourcing reliable press brake tools from manufacturers since 1965 for regional use.
Questions & Answers
What is the Straight Punch 30° Silver H150mm B26mm EU3212 SMAX?
The Straight Punch 30° Silver H150mm B26mm EU3212 SMAX is a new S-body joggle punch from TFI Co., manufacturer of steel blades since 1965. This Silver Class tool offers 150mm working height, 26mm body, and 30° angle for stepped offset flange forming at depth. It is designed for complex architectural and enclosure assemblies across the UAE and GCC. Reference BPS_150_26_30_S.
How is the 30° angle applied in the EU3212 SMAX punch?
The 30° angle in the EU3212 SMAX punch is applied to achieve precise steppd offset flange forming at depth. Combined with the 150mm height and S-body design, it delivers accurate results for intricate bends in architectural and enclosure fabrication. This configuration supports high-precision work required by production managers in GCC facilities.
Can the Silver Class punch handle complex architectural assemblies?
Yes, the Straight Punch 30° Silver H150mm B26mm is engineered for complex architectural and enclosure assemblies across the UAE and GCC. Its 26mm body, 150mm working height, and 30° angle enable effective joggle forming and offset flanges in press brake tooling applications for regional metal fabricators.
Does this punch come with a reference code and technical data sheet?
Yes, the EU3212 SMAX Straight Punch uses reference BPS_150_26_30_S and includes a data sheet listing length of 3200 mm, width of 150 mm, and thicknss of 26 mm. It is a new product with punch height of 150.00 mm, 30° angle, and Silver Class rating for industrial forming operations.
Which features make the H150mm B26mm punch suitable for the GCC market?
The 150mm working height, 26mm body, 30° angle, and S-body joggle design make the Silver Class Straight Punch suitable for the GCC market. It excels in stepped offset flange forming for complex architectural and enclosure assemblies, meeting the needs of expert fabricators and procurement teams in the Middle East.
How can I purchase the BPS_150_26_30_S Straight Punch for my project?
To purchase the BPS_150_26_30_S 150mm height 30° Silver Class punch for architectural assemblies in the UAE or GCC, use Chat for the fastest response. Complete the online form or call our team to specify your requirements for this EU3212-S-MAX joggle punch. TFI Co. has delivered industrial tooling solutions since 1965.
TFI Co. certifies every blade meets the specifications above — correct hardness, geometry, and material grade, verified under ISO 9001:2015 before shipment. Achieving the stated performance figures also requires correct installation, operation within rated parameters, and scheduled maintenance. Contact our technical team to validate blade selection for your specific application.
Need a Different Size? Send Specs on Telegram
Get Fast Pricing on Whatsapp
Request a Quote
TFI Co. commits to manufacturing and supplying precision press brake tooling such as the EU3212 SMAX straight punch for industrial buyers in the UAE, GCC and wider regional markets.
- This 150 mm height, 26 mm body, 30° S-body joggle punch is produced since 1965 to achieve precise stepped offset flange forming at depth for complex architectural and enclosure assemblies.
- It supports high-precision joggle bending workflows and delivers accurate results for intricate bends in UAE and GCC sheet metal fabrication by expert metal fabricators and production teams.
- Performance values may vary by context, use and configuration.
