EU3213-MAX Straight Punch 86°, 150mm Height, Silver Class
Data Sheet for EU3213 Silver Class Straight Bending Punch Upper Tool
Product Dimensions
Length: 3200 mm
Width: 150 mm
Thickness: 26 mm
Product Overview
TFI Co. supplies the EU3213 Silver Class straight bending punch upper tool for press brake machines, catering to the metalworking and sheet metal fabrication industries across the UAE, Saudi Arabia, Oman, and Qatar. The EU3213 is a precision-engineered straight upper punch designed for standard press brake forming operations. This tool is readily available for immediate dispatch from TFI Co. logistics centers.
Featuring a working height of 150 mm and a body thickness of 26 mm, the EU3213 offers a standard 86° bending angle, making it ideal for general sheet metal work and production-line setups.
This tool is crafted from 42CrMo (Chromium-Molybdenum Steel), a high-strength alloy chosen for press brake tooling due to its exceptional toughness, fatigue resistance, and consistent dimensional stability under cyclic bending loads. The tip contact zone is precision-hardened to 55–62 HRC, while the body maintains a hardness of 45–50 HRC. All body thickness dimensions adhere to DIN 7168 Fine tolerance standards, ensuring a consistent clamping fit and tool interchangeability across compatible press brake systems.
Technical Specifications
- Punch Height (H): 150.00 mm
- Body Thickness (B): 26.00 mm
- Bending Angle: 86.00°
- Material Grade: 42CrMo4
- Tip Hardness: 55–62 HRC
- Body Hardness: 45–50 HRC
- Tolerance Class: DIN 7168 Fine
- Standard Set Length: 835 mm
- Segment Composition: 1×100mm ear + 3×800mm + 2×100mm + 2×200mm + 1×100mm ear
- Product Grade: Silver Class
- EU Drawing Reference: EU3213
Clamp System Compatibility
- AFH / Euro Style: Compatible with AMADA™, Bystronic™, Durma™, Ermaksan™, and most Euro-clamp CNC press brakes
- AMADA™ Direct-Mount: Compatible with AMADA™ native clamp systems
Parameters Confirmed Upon Order
The following parameters are customer-defined and will be confirmed by TFI Co. via email upon receipt of the order:
- Tip Radius (R): Standard options include 0.6 mm, 0.8 mm, and 1 mm. Custom radius available upon request.
- Segment Composition: Standard configuration is 1×100mm ear + 3×800mm + 2×100mm + 2×200mm + 1×100mm ear. Custom segment arrangements are available at no additional cost.
Delivery Coverage
TFI Co. ships this product across the GCC region. Delivery is confirmed upon order to the following countries and territories:
- UAE: Delivered across all 7 emirates – Ajman, Abu Dhabi, Dubai, Fujairah, Ras Al Khaimah, Sharjah, and Umm Al Quwain
- Saudi Arabia: Delivered across all 13 regions – Riyadh, Makkah, Al Madinah, Al Qasim, Eastern Province, Asir, Tabuk, Hail, Northern Borders, Jazan, Najran, Al Bahah, and Al Jawf
- Qatar: Delivered across all 7 municipalities – Ad Dawhah (Doha), Al Khor, Ash Shamal, Ar Rayyan, Umm Salal, Al Wakrah, and Az Za’ayin
- Oman: Delivered across all 11 governorates – Al Batinah North, Al Batinah South, Al Buraymi, Ad Dakhiliyah, Muscat, Musandam, Al Sharqiyah North, Al Sharqiyah South, Al Wusta, Az Zahirah, and Dhofar
- Kuwait: Delivered across all 6 governorates – Al Ahmadi, Al Farwaniyah, Hawalli, Al Jahra, Al Asimah (Kuwait City), and Mubarak Al-Kabeer
- Bahrain: Delivered across all 4 governorates – Al Asimah (Manama), Al Janubiyah, Al Muharraq, and Ash Shamaliyah
Disclaimer
TFI Co. provides these technical specifications as a reference only. TFI Co. accepts no liability if a third-party manufacturer applies these specifications and fails to achieve equivalent product quality. The manufacturing outcomes of any external production facility are entirely beyond TFI Co.’s control and responsibility.
All prices shown on this page are indicative estimates only and are subject to market fluctuations. For precise and up-to-date pricing, please contact us directly. You can scan the QR code on the product images, use the live chat button on this page, or find the contact number for your region at the bottom of this page.
Additional Information
TFI Co. offers Silver Class straight bending punch upper tools for press brake machines, serving the metalworking and sheet metal fabrication industries. These tools are manufactured from high-quality alloy steel, precision-hardened and ground, and thoroughly tested for multi-U-channel bending, box forming, and profile production on press brake machines. They are available across the United Arab Emirates (Abu Dhabi, Dubai, Sharjah, Ajman, Ras Al Khaimah), the Kingdom of Saudi Arabia, Oman, and Qatar.
The dimensions of this tool are 150 mm × 26 mm (working height × body thickness), with a bending angle of 86°.
For more details or to place an order, contact us today.
TFI Co. supplies the EU3213 Silver Class straight bending punch upper tool, a precision-engineered 86° straight punch with 150 mm height designed for standard press brake forming operations in sheet metal fabrication. This page delivers the exact product data sheet with dimensions of 3200 mm length, 150 mm width and 26 mm thickness, allowing metal fabricators, production managers and procurement teams across the UAE, Saudi Arabia, Oman and wider GCC to confirm specifications, assess compatibility with their machines, and place orders for immediate dispatch from our logistics centers. As a manufacturer of steel blades and machine knives since 1965, TFI Co. continues to support regional metalworking requirements with reliable press brake tooling that eliminates guesswork in tool selection and delivery.
Need to Know
- Straight punches function as precision upper tools for standard forming operations on press brake machines.
- Manufacturers supply industrial press brake tools to metal fabricators in UAE and GCC markets since 1965.
- Production managers select Silver Class straight punches to optimize sheet metal bending performance.
- Metal fabricators achieve accurate bends with 150mm height punches in daily manufacturing activities.
- Maintenance teams receive immediate availability when replacing press brake tools without production delays.
Quality & Certifications
The site offers customised confirmation on request regarding qualifications and standards for its machine knives and press brake tools manufactured since 1965.
Used by metal fabricators, factory buyers, maintenance teams, production managers, and industrial procurement teams across the UAE, Saudi Arabia, Oman, GCC, and the wider Middle East. Manufacturer of Steel Blades Since 1965.
Warranty: The site offers customised confirmation on request for guarantee, replacement, and support options on all supplied industrial steel blades, machine knives, and press brake tooling.
Dimensional Data
| Product Type | Straight Bending Punch Upper Tool |
|---|---|
| Model | EU3213-MAX |
| Angle | 86° |
| Class | Silver Class |
| Height | 150 mm |
| Length | 3200 mm |
| Width | 150 mm |
| Thickness | 26 mm |
| Function | Precision straight upper punch for standard press brake forming |
| Compatible Machines | Press brake machines |
| Compatible Applications | Metalworking and sheet metal fabrication |
| Target Regions | UAE, Saudi Arabia, Oman, GCC |
| Manufacturer | TFI Co. since 1965 |
Industrial Use Cases
- Press Brake Forming: Standard straight bending operations using the EU3213-MAX 86° punch on 3200 mm press brake machines for sheet metal fabrication.
- Metal Fabricators: Daily precision forming tasks performed by metal fabricators in UAE workshops to produce consistent bends in industrial sheet metal.
- UAE Production Facilities: Integration into high-volume sheet metal bending lines at UAE manufacturing plants requiring immediate tool availability from TFI Co.
- Maintenance Teams: Rapid replacement of upper tooling by maintenance teams in GCC factories to minimize downtime on press brake equipment.
- Saudi Arabian Metalworking: Precision 150 mm height punch deployment by production managers in Saudi Arabian sheet metal facilities for standard forming operations.
- Industrial Procurement: Sourcing and specification by industrial procurement teams across Oman and Qatar for Silver Class press brake tools manufactured since 1965.
- GCC Fabrication Shops: Application in regional press brake workflows within Middle East metalworking environments for accurate straight-line bending.
- Factory Production Managers: Process optimization by production managers overseeing metal fabrication output using compatible 26 mm thickness bending punches.
Expert Answers
What is the EU3213-MAX Straight Punch 86°, 150mm Height, Silver Class?
The EU3213-MAX is a precision-engineered straight bending punch upper tool from TFI Co., manufacturer of steel blades and machine knives since 1965. With dimensions of 3200 mm length, 150 mm width, 26 mm thickness, plus 86° angle and 150 mm height, this Silver Class press brake tool is designed for standard forming operations in metalworking and sheet metal fabrication for industrial buyers across the UAE, GCC, and wider regional markets.
How is the EU3213-MAX straight bending punch configured for press brake use?
The EU3213-MAX straight bending punch is configured as an 86° upper tool with 150 mm height and overall dimensions of 3200 mm length, 150 mm width, and 26 mm thickness. TFI Co. produces this press brake tool since 1965 for direct integration into press brake machines to execute standard forming operations. It supports consistent performance in sheet metal fabrication environments serving maintenance teams and production managers in the UAE and GCC markets.
Can the EU3213-MAX Silver Class punch support standard metal forming operations?
Yes, the EU3213-MAX Silver Class punch can support standard metal forming operations as a precision straight upper tool for press brake machines. Manufactured by TFI Co. since 1965, it delivers accurate bending performance with its 86° angle, 150 mm height, and specified dimensions. This makes it suitable for metal fabricators, factory buyers, and procurement teams engaged in industrial steel applications throughout the UAE, Saudi Arabia, Oman, and Qatar.
Does the EU3213-MAX Straight Punch include specifications for immediate industrial deployment?
The EU3213-MAX Straight Punch does include full specifications for immediate industrial deployment, covering 3200 mm length, 150 mm width, 26 mm thickness, 86° angle, and 150 mm height. As part of TFI Co.’s range of press brake tools and machine knives manufactured since 1965, this Silver Class product is engineered for standard press brake forming in metalworking and sheet metal fabrication across UAE, GCC, and wider Middle East industrial sectors.
Which straight punch variant suits 86° bending with 150 mm height?
The EU3213-MAX Silver Class variant suits 86° bending with 150 mm height requirements. This straight bending punch upper tool features 3200 mm length, 150 mm width, and 26 mm thickness for press brake applications. Produced by TFI Co. since 1965, it aligns with the needs of expert metal fabricators and production managers seeking reliable press brake tools and industrial knives for precision sheet metal work in GCC and regional markets.
When can industrial buyers in the UAE and GCC obtain the EU3213-MAX punch?
Industrial buyers in the UAE and GCC can obtain the EU3213-MAX punch immediately as it is readily available for dispatch from TFI Co. logistics centers. TFI Co., manufacturer of steel blades and press brake tools since 1965, maintains stock of this Silver Class straight bending punch to support metalworking and sheet metal fabrication operations. This ensures prompt supply to factory buyers and maintenance teams across Saudi Arabia, Oman, Qatar, and wider regional markets.
TFI Co. certifies every blade meets the specifications above — correct hardness, geometry, and material grade, verified under ISO 9001:2015 before shipment. Achieving the stated performance figures also requires correct installation, operation within rated parameters, and scheduled maintenance. Contact our technical team to validate blade selection for your specific application.
Upgrade to Promecam Tooling
Increase Bending Flexibility
Improve Bending Accuracy with CNC Control
Customize Your Bending Radius
Handle Complex Bending Profiles
TFI Co. supplies precision-engineered press brake punches to exact specifications for industrial sheet metal forming.
- Manufacture and supply of the EU3213-MAX 86° straight punch with verified 3200 mm length, 150 mm height, 26 mm thickness for standard bending operations on 3200 mm press brakes in metalworking and sheet metal fabrication.
- Targeted delivery to expert industrial buyers, metal fabricators and production teams across the UAE, GCC and wider regional markets for daily precision forming tasks that produce consistent bends.
- Forming performance, bend accuracy and tool life may vary by machine configuration, material grade and specific operational context.
